Model No.

MNTDAMR825501

Frequency range

806~960/1710~2500MHz

Gain

2/5dBi

Horizontal Beamwidth

  360º

Vertical Beamwidth

 55/30º

Un-roundness

±3dB

VSWR

≤1.5

Impedance

50Ω

Polarization

Vertical

Max.Power

100W

Connector

 N-female

Lightning Protection

                      DC Ground

Mechanical Specification

Dimension

￠350x410mm

Weight

0.25kg

Rated Wind Velocity

 60m/s

Reflector material

Aluminum

Operational Humidity

   < 95％

Radome material

                        Fiberglass

Radome Color

                           Green

Operating temperature

  -40～55ºC
