With rotating fixation adjustable tilting mounting kit Supporting 1920~2170MHz Good durable performance
|
Electrical Specification |
|
|
Model No. |
MNTOSPAR01 |
|
Frequency Range |
1920~2170MHz |
|
Gain |
8±1dBi |
|
Horizontal Beamwidth |
75±5° |
|
Vertical Beamwidth |
55° |
|
F/B Ratio |
≧18dB |
|
VSWR |
≦1.5 |
|
Impedance |
50Ω |
|
Polarization |
Vertical |
|
Max. Power |
100W |
|
Connector |
N-Female |
|
Lightning Protection |
DC Ground |
|
Mechanical Specification |
|
|
Dimension |
100*100*23mm |
|
Weight |
0.2Kg |
|
Rated Wind Velocity |
36.9m/s |
|
Reflector material |
Aluminum |
|
Radome material |
ABS |
|
Operating temperature |
- 40～55℃ |
